    Pre-Painted Steel Square Down Pipe Roll Forming Machine
    Pre-Painted Steel Square Down Pipe Roll Forming Machine
  • Pre-Painted Steel Square Down Pipe Roll Forming Machine
  • Pre-Painted Steel Square Down Pipe Roll Forming Machine
  • Pre-Painted Steel Square Down Pipe Roll Forming Machine
  • Pre-Painted Steel Square Down Pipe Roll Forming Machine
    • Pre-Painted Steel Square Down Pipe Roll Forming MachinePre-Painted Steel Square Down Pipe Roll Forming MachinePre-Painted Steel Square Down Pipe Roll Forming MachinePre-Painted Steel Square Down Pipe Roll Forming Machine

    Pre-Painted Steel Square Down Pipe Roll Forming Machine

    ​ This square down pipe roll forming machine can process 406mm width pre-painted steel coil and galvanized coil into square shape for down pipe used. Whole roll forming machine is 17 steps, and the driving motor is 11KW, suitable for 0.4-0.8mm material thickness. We can custom manufacture full set machines for roll forming square shape, pipe bending and shrinking.

        Suitable Width: 406mm

        Material Thickness: 0.4-0.8mm or customized

        Forming Station: 17 steps

        Shaft Diameter: 75mm

        Producing Speed: 15-25m/min or custom design machine according to your required speed

        Cutting Blade Material: Cr12

    INQUIRY NOW
    PRODUCT CATEGORY
    New Products
    DESCRIPTION

    Pre-Painted Steel Square Down Pipe Roll Forming Machine

    Compare to PVC pipe, of course it is the long working life. Our steel down pipe roll forming machine is the automatic producing line, it is the steel roof construction company's good choice. The roll forming machine can finish roll forming section, shrink connecting head section and bending angle section on one machine, it is real one-stop purchase. So it is your good choice to choose a steel down pipe roll forming machines for expending your roof system or pipe system business.

     Technical Parameter

    Parameters Specification
    Voltage 380V/50HZ/3PH
    Driving Motor 11KW
    Hydraulic Press/Cutting Motor 5.5KW
    Forming Steps 17
    Working Speed 15-25m/min
    Material Width 406mm
    Thickness for Steel 0.4-0.8mm
    Shaft Diameter 75mm
    Shaft Material High grade 45# forged steel
    Roller Material 45# steel with polished and heat treatment
    PLC Cabinet Schneider, Mitsubishi or Delta
    Encoder Omron
    Sprocket Wheel 45 steel high-frequencies quench
    Cutting Blade Material Cr12 steel
    Machine Frame Material Fine welded structural steel;
    Roofing Material PPGI, GI steel G245-345, aluminum sheet
    Painted Color Blue+Gray White Or Customization
    Overall Size 10800*1050*1100mm
    Weight 4500KGS


    Sample Pictures

    China manufacture down pipe forming machine



    square pipe roll forming machine China


    Machine key Parameters


    Gear/Sprocket driving;14-step to form

     Machine frame: H350 beam, side wall thickness: 18mm

    Rollers manufactured from 45# steel, CNC lathes, hard Chrome Coated

    Shafts Diameter=ф75mm, Precision Machined, fine Polished

    Main motor =7.5KW, Frequency speed control

    Forming speed: Approx. 10-15m/min (not include crimping action speed)

    Whole producing line can produce straight down pipe and elbow shape down pipe

    If no need elbow function, loose the mold freely



     This Square Down Pipe Roll Forming Machine is a complete, all-in-one system that handles every stage of down pipe production. By incorporating multiple functions into one machine, the need for additional equipment is eliminated, making it a cost-effective choice for businesses. This one-stop purchase simplifies operations and enhances production capabilities.
