Main motor: 22KW or 30KW
Forming Speed: 18-25/min (depends on user's requirements)
Bottom size range: 80-300 for C shape
Forming Steps: 15
Shaft Diameter: 75/90mm
Control Type: PLC system with famous brand encoder inspect speed
Parameters | Specification |
Voltage | 380V/50HZ/3PH or customized |
Driving Motor | 22KW or 30KW |
Hydraulic Press/Cutting Motor | 7.5KW |
Forming Steps | 15 stations |
Working Speed | 18-25m/min (without punching and cutting action speed) |
Bottom Size | 80-300mm |
Waist Height | 40-80mm |
Lip Width | 5-15mm |
Thickness for Steel | 1.5-3mm |
Shaft Diameter | 75/90mm |
Shaft Material | High grade 45# forged steel |
Roller Material | 45# steel with polished and heat treatment |
PLC Cabinet | Schneider, Mitsubishi or Delta |
Encoder | Omron |
Sprocket Wheel | 45 steel high-frequencies quench |
Cutting Blade Material | Cr12 steel |
Machine Frame Material | Fine welded structural steel; |
Roofing Material | PPGI, GI steel G245-345 |
Painted Color | Blue+Gray White Or Customization |
Overall Size | 9800*1600*1600mm |
Weight | 9000KGS |
