Pre-painted Steel Snap Lock Metal Roofing Machine

Pre-painted Steel Snap Lock Metal Roofing Machine

Machine Detailed Pictures

• The Snap Lock Metal Roofing Machine line is efficient and high-quality roofing sheet production. At the beginning of the production line, an entry feeding bench with a manual pre-shear device has been installed. This device allows operators to manually cut off no use steel coil heads and tails.
• Upon entering the roll forming section, A film coated device is strategically positioned here, ready to apply a protective or decorative film to the roof sheets if required. This enhances both the durability and aesthetic appeal of the final product.
• The current Snap Lock Metal Roofing Machine is equipped with a grid type safety cover over the roll forming section. This cover provides a physical barrier, reducing the risk of accidents and ensuring a safer workplace for all operators.
• In addition to being known as the Snap Lock Metal Roofing Machine, this high quality roll forming equipment can also be referred to as a roofing sheet machine, roof panel machine, roofing sheet making machine, metal roof bending machine, and even a metal roof seamer machine (if it includes seaming capabilities). It is popular used for steel roof system manufacturing industry.

Profile Design Drawing

Raw Material Basic Information

• Thickness: 0.3-0.7mm
• 0.5mm thickness is for inspection, common use
• Effective Width:305/406/457mm
• Coil Width for profiles:458/559/610mm
• Pre-painting steel, Aluminum sheet Tension Grade: Q235MPa

Roll Forming Machine Technical Parameter
