The BEMO roof panel system provides the most advanced and versatile structural standing seam roofing system available in today’s architecturally demanding market. These systems offer the highest wind uplift ratings with the greatest flexibility of any structural standing seam panel in the world. With its bold lines and its ability to be smoothly convex, concave or serpentine curved, this roof panel system offers years of low-maintenance service combined with high visual-impact applications.

Xiamen Thrive brand size interchangeable standing seam metal roof machine is designed for making Bemo roof panel system in batch fully automatically. It designed with adjustable width rollers and design, side roller processing method for special width.

Can be matched with special fan shape slitting and cut to length machine.

 Machine Video

About standing seam metal roof machine

Equipment size: 3500mm in length, 1000mm in width, and 1050mm in height.

Working mode: Three roll feeding, combined with hydraulic and servo motors for molding.

Processing scope: Straight board; Fan shaped board (any model within the range of 230-600 can be automatically or manually adjusted).

Scope of processing sheet metal: Aluminum magnesium manganese, (0.76-1.2) color plate (0.3-0.7).

The working mode is automatic and continuous rolling forming, which can be manually and automatically controlled.

Main motor power: 5.5kw equipped with 5 # reducer (vertical motor).

Main engine transmission mode: Gear transmission.

Equipment functions: Web width is interchangeable from 280mm to 600mm

Cutting Action: Hydraulic cutting, stop to cut, one set cutting blade adjustable for all sizes

Roller material: Cr15 quenching and tempering followed by surface plating with hard chromium treatment.

Forming speed:18m/ min.

Our standing seam metal roof machine ensures high precision and efficiency in creating durable and aesthetically appealing roofing panels. With these advanced capabilities, Xiamen Thrive stands at the forefront of the roll forming machine industry.
