    Custom Design Window Guide Rail Roll Forming Machine
    Custom Design Window Guide Rail Roll Forming Machine
  • Custom Design Window Guide Rail Roll Forming Machine
  • Custom Design Window Guide Rail Roll Forming Machine
  • Custom Design Window Guide Rail Roll Forming Machine
  • Custom Design Window Guide Rail Roll Forming MachineCustom Design Window Guide Rail Roll Forming MachineCustom Design Window Guide Rail Roll Forming Machine

    Custom Design Window Guide Rail Roll Forming Machine

    In the area of construction and architecture, precision is very important. Every component must align seamlessly to ensure the smooth operation and longevity of the final structure. When it comes to window rails, this precision becomes even more critical. Choose the Window Rail Roll Forming Machine, a marvel of engineering designed to craft flawless window rails with utmost accuracy and efficiency.

        Driving Motor: 5.5KW

        Forming Station: 16 steps

        Working Speed: 15-25m/min

        Hydraulic Motor: 3KW

        Steel Thickness: 0.4-0.8mm

    Custom Design Window Guide Rail Roll Forming Machine


    Roll Forming Machine Technical Parameter


    Parameters Specification
    Voltage 380V/50HZ/3PH or customized
    Driving Motor 5.5KW
    Hydraulic Cuting Motor 3KW
    Forming Steps 16
    Working Speed 15-25m/min
    Material Width 121mm
    Thickness for Steel 0.4-0.8mm
    Shaft Diameter 65mm
    Shaft Material High grade 45# forged steel
    Roller Material 45# steel with polished and heat treatment (base on raw material type)
    PLC Cabinet Schneider, Mitsubishi or Delta
    Encoder Omron
    Sprocket Wheel 45 steel high-frequencies quench
    Cutting Blade Material Cr12 steel
    Machine Frame Material Fine welded structural steel;
    Roofing Material PPGI, GI steel G245-345
    Painted Color Blue+Gray White Or Customization
    Overall Size 6500*1350*1550mm
    Weight 2600KGS

      1. Machine Description

      2. In the area of construction and architecture, precision is very important. Every component must align seamlessly to ensure the smooth operation and longevity of the final structure. When it comes to window rails, this precision becomes even more critical. Choose the Window Rail Roll Forming Machine, a marvel of engineering designed to craft flawless window rails with utmost accuracy and efficiency.


      3. steel rail making machine


      4. Crafting Excellence
        At the heart of this roll forming machine lies a meticulous design tailored for perfection. With a capacity ranging from 0.4mm to 0.8mm aluminum sheets, it caters to a wide spectrum of industry needs. The choice of 16 stations in the roll forming process ensures intricate detailing and precise shaping of the rail, leaving no room for error. Each station plays a crucial role, meticulously shaping the raw material into the desired form.

        Hydraulic Cutting: A Stroke of Precision
        The decision to incorporate hydraulic cutting into the design was a strategic one. Precision is not merely a goal; it is an uncompromising standard. Hydraulic cutting ensures clean, sharp cuts, leaving behind no imperfections that could compromise the integrity of the rail. This cutting-edge technology guarantees uniformity, contributing to the seamless operation of the final product.

        Straightness: The Key to Smooth Functionality
        One of the fundamental aspects of window rails is their straightness. Any deviation from this straight path can lead to operational issues, compromising the functionality of the entire window system. Recognizing this, the Window Rail Roll Forming Machine prioritizes straightness throughout the manufacturing process. From the initial shaping to the final cut, every step is meticulously executed to maintain the straightness of the rail, ensuring smooth functionality and customer satisfaction.

      5. window rail roll forming machine

    Custom Design Window Guide Rail Roll Forming Machine
